OUR
PRODUCT LINE
|
2 Roll Mills:
Polymer mills with roll diameters of 110, 150 and 200 mm. We
offer manual versions and fully automatic hands-free
computerized mills used for color matching, quality control and
research. |
|
|
Lab Blown Film Lines:
Blown film lines for film lay-flat widths of up to 200 mm.
Include features such as a twin-channel cooling ring, nip rolls,
variable speed haul-off, slitters and winder.
Co-extrusion lines for films with up to 5 layers. Large film
tower with twin pillars, modern design enclosure, pneumatic nip
rolls, infinitely variable-speed drive, high-capacity cooling
ring, film wind-up, and freestanding central control cabinet
incorporating all controls for the tower and extruders. |
| |
|
Hydraulic Lab Presses:
Hydraulic laboratory presses from 20 to 80 metric tons platen
pressure. A double set of heating and cooling platens are
standard. Available with a fully automatic platen insert cooling
system as well as many platen configurations and control
options. |
|
|
Filter Test:
Filter test with and without a gear pump for accurate quality
testing and standardization of masterbatches and compounds.
Standard filter sizes from 15 down to 5 microns. |
| |
|
Single Screw Lab Extruders:
Single screw laboratory extruders with diameters of 12,5, 20, 25
and 30 mm, all with an L/D ratio of 30:1. The 20 mm extruder is
available as a table top version. The 25 and 30 mm extruders are
available both in vented or non-vented versions with plain
screws or equipped with a Maddock mixing section, as well as a
pineapple mixer at the screw tip. |
|
|
High Speed Lab Mixers:
25 and 75 liter pilot plant high-speed mixers with variable
impeller speed, automatic mixing cycles and optional
water-cooled impeller. |
| |
|
Co-rotating Twin Screw
Extruders:
Modular co-rotating twin screw extruders have clam-shell barrels
and our unique super hard tool steel barrel inserts. Fully
closed barrels are an option. Machines are available with 16, 20
and 26 mm screw diameters and L/D ratios of 32:1 and 40:1. |
|
|
Small High Speed Mixers:
Manual and computerized 5 and 10 liter high-speed mixer with
optional cooling. |
| |
|
Chill Roll Film and Sheet Casting Lines:
Chill roll film and sheet casting lines are available both as
floor and bench top versions. Flat die widths range from 125 mm
for bench top versions up to 300 mm for floor versions. Dies
have adjustable lips for sheet thickness from 0.3 to 1.5 mm or
film thickness down to 0.01 mm. All three rolls are hard
chromed, mirror polished and cored for water cooling and
heating. Polishing roll is pneumatically operated.
Co-extrusion flat film and sheet lines for up to 5 layers.
Suitable for producing film and sheet with materials such as PE,
PP, PS, ABS, PVC, PET, PC, etc. |
|
|
Bench Top High Speed Mixers:
Bench top 10, 5 and 1.5 liter mini high-speed mixers with
variable speed drive and easily removable mixing bowl. |
| |
|
